$424.56 Add to Cart

OWON AG1012F Function generator Signal Waveform 10MHz AM FM PM FSK PWM Sweep

OWON AG1012F Function generator Signal Waveform 10MHz  AM FM PM FSK PWM Sweep

More than 10 available

Details

Shipping: USPS calculated - check

Condition: Brand new

*The store has not been updated recently. You may want to contact the merchant to confirm the availability of the product.

  • OWON AG1012F Function generator Signal Waveform 10MHz  AM FM PM FSK PWM Sweep
  • OWON AG1012F Function generator Signal Waveform 10MHz  AM FM PM FSK PWM Sweep
  • OWON AG1012F Function generator Signal Waveform 10MHz  AM FM PM FSK PWM Sweep
Tweet
  • Description
AG1012F:Dual-channel Arbitrary Waveform Generator Product Series : AG Series Main Features- Advanced DDS technology, max 60MHz frequency output- Up to 250MS/s sample rate, and 1μHz frequency resolution- Vertical Resolution : 14 bits, up to 1M arb waveform length- Comprehensive waveform output : 5 basic waveforms, and 48 built-in arbitrary waveforms- Comprehensive modulation functions : AM, FM, PM, FSK, PWM, Sweep, and Burst- High-accuracy frequency counter integrated, supported range 100mHz - 200MHz- Supported SCPI- 4 inch high resolution (480 × 320 pixels) TFT LCD displayApplicationdesign and debug circuit function test education and training Model AG1012F Channel dual Frequency Output 10MHz Sample Rate 125MS/s , Vertical Resolution 14 bits Waveform Standard Waveform Sine, Square, Pulse, Ramp, and Noise Arbitrary Waveform Exponential Rise, Exponential Fall, Sin(x)/x, Step Wave, and others, total 48 built-in waveforms, and user-defined arbitrary waveform Frequency (resolution 1μHz) Sine 1μHz - 10MHz , Square 1μHz - 5MHz ,Pulse 1μHz - 5MHz , Ramp 1μHz - 1MHz Noise 25MHz (-3dB) ,Arbitrary Waveform 1μHz - 10MHz Amplitude Amplitude 1m Vpp - 10 Vpp (50Ω), 1m Vpp - 20 Vpp (high impedance) Resolution 1mVpp or 14 bits DC Offset Range (AD+DC) ±5V (50Ω), ±10V (high impedance) DC Offset Range Resolution 1mV Load Impedance 50Ω (typical) Arbitrary Waveform Wave Length 2 pts to 8K pts, Sample Rate 125MS/s, Vertical Resolution 14 bits Non-volatile Memory 26 waveforms Modulation Modulation Waveform / AM, FM, PM, FSK,Linear / Logarithm Sweep,and Burst / AM, FM, PM, FSK,Linear / Logarithm Sweep,and Burst Modulation Frequency / 2mHz to 20.00KHz(FSK 1μHz - 100KHz) / 2mHz to 20.00KHz(FSK 1μHz - 100KHz) Counter Function / Frequency Period, +Width,-Width +Duty, and -Duty / Frequency Period, +Width,-Width +Duty, and -Duty Frequency Range / 100mHz ~ 200MHz / 100mHz ~ 200MHz Frequency Resolution / 6 digits / 6 digits Power Amplifier Specification (Optional) IBandwidth DC - 100 kHz Gain X 10 Max Output Power 10 W Max Output Voltage 22 Vpp Input / Output Display 4 inch (480 × 320 pixels) TFT LCD Type external reference clock input / output counter, external modulationinput / output, external triggerinput / output, external reference clockinput / output external reference clock input / output counter, external modulationinput / output, external triggerinput / output, external reference clockinput / output Communication Interface USB host, USB device, RS232 Mechanical Dimension (W×H×D) 235 × 110 × 295 (mm) Weight (without package) 3.00 kg What's in the package:Power code x1 CD Rom x1 Quick Guide x1 USB Cable x1 Q9X1
... [Full Description]
