XDS3204AE 4CH DSO + 200MHz Bandwidth，1GS/s sample rate + 14-bit high resolution ADC + 40M record length 70,000 wfms/s waveform refresh rate + low back ground noise + 8 inch 800 x 600 multi-touch LCD, more user-friendly operation experience + SCPI, and LabVIEW supported + multi- trigger, and bus decoding function + multi-interface integration - USB host, USB device, USB port for PictBridge, LAN, AUX 1. XDS3204AE introduce 14 bits hardware ADC, the precision is 64 times against other oscilloscope on market. Equipping with OWON’s original magnifier function, it can observe the signal low down to 31.25μV/div. 2. platform - restore the waveform detail fully 3. multi-level grayscale, and color temperature display 6. built-in multimeter module, with auto-scale, and data logging function 4. multi-trigger supported - Logic, Time-out, I2C, SPI， RS232, Runt, Windows, Nth Edge, and CAN 5. serial bus coding available in I2C, SPI, RS232, and CAN 8. Its multi-point touch function improves operation efficiency considerably 7. its built-in WiFi module facilitates mobile device connecting with XDS seris product, to get access to remote control, together with simultaneous measurement result display via app s/w, waveform data-saving,checking, co-sharing is possible, co-analyzing hence realizes 10. optional battery makes floating measurement possible, advancing the operation convenience ＋Performance Specifications Model XDS3204AE Bandwidth 200MHz Sample Rate 1GS/s Vertical Resolution (A/D)) 14 bits Record length 40M Waveform Refresh Rate 70,000 wfms/s Horizontal Scale (s/div)) 2ns/div - 1000s/div, step by 1 - 2 - 5 Rise Time (at input, typical) ≤1.7ns Channel 4 Display 8" color LCD, 800 x 600 pixels display Input Impedance 1MΩ ± 2%, in parallel with 15pF ± 5pF Channel Isolation 50Hz : 100 : 1, 10MHz : 40 : 1 Max Input Voltage 1MΩ ≤ 300Vrms; DC Gain Accuracy ±3% DC Accuracy average≥16：±（3% +0.05div) for △V Probe Attenuation Factor 0.001X - 1000X, step by 1 - 2 - 5 LF Respond (AC, -3dB) ≥5Hz Sample Rate / Relay Time Accuracy ±2.5ppm Interpolation (sinx) / x，x Interval (△T) Accuracy (full bandwidth) Single: ±(1 interval time + 1ppm x reading + 0.6ns); Average > 16: ±(1 interval time + 1ppm x reading + 0.4ns) Input Coupling DC, AC, GND Vertical Sensitivity 1mV/div - 10V/div (at input) Trigger Type Edge, Video, Pulse, Slope, Runt, Windows, Timeout, Nth Edge, Logic, I2C, SPI, RS232, Bus Decoding(optional) I2C, SPI, RS232, CAN Trigger Mode Auto, Normal, and Single Vertical Range ±2V(1mV/div～50mV/div)；±20V(100mV/div～1V/div)；±200V(2V/div～10V/div) Line / Field Frequency (video) NTSC, PAL and SECAM standard Cursor Measurement △V, and △T between cursors, △V and △T between cursors, and auto- cursors Automatic Measurement Vpp, Vavg, Vrms, Freq, Period, Week RMS, Cursor RMS, Vmax, Vmin, Vtop, Vbase, Vamp, Overshoot, Phase A→B ↑, Phase A→B↓, Preshoot, Rise Time, Fall Time,+Width, -Width, +Duty, -Duty, Duty Cycle, Delay A→B ↑, Delay A→B↓, +Pulse Count, -Pulse Count, Rise Edge Count, Fall Edges Count, Area, Cycle Area Waveform Math ＋, －, ×, ÷, FFT Waveform Storage 100 waveforms Lissajou's Figure full bandwidth Full bandwidth ±3 degrees ±3 degrees Communication Interface USB host, USB device, USB port for PictBridge, Trig Out (P/F), LAN, and VGA (optional) Frequency Counter available Power Supply 100V - 240V AC, 50/60Hz, CAT II Fuse 2A, T class, 250V Battery (optional) 3.7V, 13200mA Dimension (W x H x D) 340mmx177mmx90mm ＋Multimeter (optional) Specifications Full Scale Reading 3¾ digits (max 4000 count) Diode 0V -1.5V Input Impedance 10MΩ Continuity Test
