Specifications:

* Video Signal System: NTSC / PAL
* Compression Format: H.264
* Video Input: 16ch BNC(1.0Vp-p,75Ω)
* Video Output: VGA
* Audio: 8CH
* O.S: Windows 2000 / XP / 2003
* Display Frame Rate: NTSC: 480FPS, PAL: 400FPS
* Display Resolution: 352 × 288
* Screen Division: 1, 4, 9, 16, 25 and user-defined picture division and length-to-width ratio.
* Record Frame Rate: NTSC: 240FPS, PAL: 200FPS
* Record Resolution: 704 × 576
* Record Code Rate: 64K-2Mbps option
* Record Recording Mode: Manual, time, motion detective, sensor, pre-recording
* Playback Multi-Channel: 1-24 ch playback in time
* Playback Mode: 1, 4, 8, 16 fast playback, single frame playback
* Transmission Mode: LAN / PSTN / ISDN / ADSL
* Transmission Protocol: TCP/IP
* Connecting: Client software/ IE Browser
* Client/IE: Remote preview, recording, playback, control, support Dynamic
* Equipment: Support alarm box, RS232/485
* Alarm Event: Motion detection, video signal loss, sensor input
* Linkage: Video recording, sound alerts, alarm box output, phone alert, net inform
* Alarm Box: Support multi-protocol,1-24 ch signal input and output
* P/T/Z: Support multi-protocol,RS232/485,higspeed dome control software
* Back Up: USB, Network, CD-RW, DVD-RW backing up
* Security: Multi-lever password,, user right option, system keyboard lock
* Power: 12W
* Support 32 channels real time in one PC
* High compressed recording, can extend the time for store recording
* Support DDNS, easy to remote monitor
* Intelligent brightness control and the function of magnifier
* The recording file can be save as EXE file, no need other media player





How to Select a Video Capture Card:

* Determine the type of PC expansion slot that you will plug your video capture card into your computer. The three major PC adapter interfaces for video capture cards are PCI, PCI-Express (or PCI-e), and USB. This is important because you will need to see which one will fit your PC. If you are not sure use the reference link at the end of this article to motherboards.org about PC Expansion Slots
* Determine the type of video format that the video capture card will be receiving. The two standard video formats are Standard Definition (SD) and High Definition (HD). Video capture cards vary in the types of definition as well as the format of HD content. Also some video capture cards do hardware encoding which formats the video content into PC readable files. Check if the video capture card is software or hardware encoding as this can affect your PC system resources such as CPU and Memory requirements
* Choose the number of tuners for the video capture card. Most of the early video capture cards could only capture one video source at a time. Now manufacturers sell dual tuners or multi-tuner video capture cards that allow more than one video source to capture per PC expansion slot
* Other media type considerations. Some video capture cards can take FM audio signals which allow to capture streaming audio. Also another consideration are remote controls that allow to change channels with your video capture card. Make an assessment of all of your requirements before purchasing

Package Included:

* 1 x 16 Channel DVR Card
* 2 x VGA Connector with BNC
* 1 x Software CD
