AMD Athlon II X2 240 CPU - 2800 MHz 65 Watt Dual-Core - ADX2400CK23GQ, ADX240OCGQBOX


Brand: AMD
Model: Athlon II X2 240
P/N: ADX240OCK23GQ
P/N:

Stepping codes CAEEC AE NAEIC AE UAEIC AE WAEIC AE
Frequency ? 2.8 GHz / 2800 MHz
Bus speed ? 533 MHz Memory controller
One 2000 MHz 16-bit HyperTransport link
Clock multiplier ? 14
Package 938-pin organic micro Pin Grid Array (UOF938)
Socket Socket AM2+

Socket AM3
Fan/heatsink AV-Z7LH01G101-2309
Introduction date July 22, 2009
Price at introduction $60
Architecture / Microarchitecture
Instruction set x86
Microarchitecture K10
Processor core ? Regor
Core stepping ? DA-C2
CPUID 100F62
Manufacturing process 0.045 micron
234 million transistors
Die 117.5mm2
Data width
64 bit
The number of CPU cores 2
The number of threads 2
Floating Point Unit Integrated
Level 1 cache size ?
2 x 64 KB instruction caches
2 x 64 KB data caches
Level 2 cache size ?
2 x 1 MB
Level 3 cache size None
Multiprocessing Uniprocessor
Extensions & Technologies

MMX instructions
Extensions to MMX
3DNow! technology
Extensions to 3DNow!
SSE / Streaming SIMD Extensions
SSE2 / Streaming SIMD Extensions 2
SSE3 / Streaming SIMD Extensions 3
SSE4a ?
AMD64 / AMD 64-bit technology ?
AMD-V / AMD Virtualization technology

Security Features EVP / Enhanced Virus Protection ?
Low power features

Cool'n'Quiet 3.0
CoolCore Technology ?

Integrated Graphics Processing Unit
None
Integrated peripherals / components
Memory controller
The number of controllers: 1
Memory channels (per controller): 2
Memory channels (total): 2
Supported memory: DDR2-1066, DDR3-1066
Other peripherals HyperTransport 3 technology
Electrical / Thermal parameters
V core ? 0.85V - 1.425V
Maximum operating temperature ? 55°C - 74°C
Thermal Design Power ? 65 Watt



Manufacturer: AMD Measured frequency: 2800 MHz
CPU Family: Athlon II X2 Comment: 0943CPDW
Model Number: 240
Part number (supplied): ADX240OCK23GQ Submitted by: xhoba
Part number (guessed):
ADX240OCK23GQ
Submitted on:
Stepping Code: NAEIC AE CWID version: 0.5
General information
Vendor: AuthenticAMD
Processor name (BIOS): AMD Processor model unknown
Processor name (CWID): AMD Athlon(tm) II X2 240 Processor
Cores: 2
Logical processors: 2
Processor type: Original OEM Processor
Core stepping: DA-C2
CPUID signature: 100F62
Family: 16 (010h)
Model: 6 (06h)
Stepping: 2 (02h)
Socket: AM2+ and/or AM3

Cache details
Cache: L1 data L1 instruction L2
Size: 2 x 64 KB 2 x 64 KB 2 x 1 MB
Associativity: 2-way set associative 2-way set associative 16-way set associative
Line size: 64 bytes 64 bytes 64 bytes
Lines per tag: 1 1 1

Supported instructions
Instruction set extensions Additional instructions
MMX Advanced Bit manipulation
AMD extensions to MMX CLFLUSH
3DNow! CMOV
Extensions to 3DNow! CMPXCHG16B
SSE CMPXCHG8B
SSE2 FXSAVE/FXRSTORE
SSE3 MONITOR/MWAIT
SSE4A POPCNT
PREFETCH/PREFETCHW
RDTSCP
SKINIT/STGI support
SYSCALL/SYSRET
SYSENTER/SYSEXIT

Integrated features and technologies
Major features Other features
On-chip Floating Point Unit 1 GB large page support
64-bit / Intel 64 100MHz multiplier control
NX bit/XD-bit 128-bit SSE instructions
Secure Virtual Machine (Virtualization) 36-bit page-size extensions
PowerNow! / Cool'n'Quiet Advanced programmable interrupt controller
Core multi-processing legacy mode
Debugging extensions
Extended APIC space
FXSAVE/FXRSTOR optimizations
Hardware P-state control
Hardware thermal control
Instruction based sampling
LAHF/SAHF support in 64-bit mode
LBR virtualization
LOCK MOV CR0 means MOV CR8
Machine check architecture
Machine check exception
Memory-type range registers
Misaligned SSE mode
Model-specific registers
Nested page tables
OS visible workaround
Page attribute table
Page global extension
Page-size extensions (4MB pages)
Physical address extensions
SVM lock
Software thermal control
Support for NRIP save
THERMTRIP
TSC rate is ensured to be invariant across all states
Temperature sensor
Time stamp counter
Virtual 8086-mode enhancements
Watchdog timer support


Condition: Item was pulled from working workstations. Seller not responsible for compatibility problems.

Contents: CPU only. No other accessories.
Item is sold as-is. All sales are final. No returns are accepted on this Clearance Item.

Image for reference only, not of actual unit.


Location: [installed in M4A785-M motherboard]
