Features:

• Plug and play: use the original car audio host disk box interface original position installation, simple and fast, and the original car perfectly integrated.
• Support HFP Bluetooth hands-free call: can be controlled by the original car audio host and steering wheel buttons to answer/hang up the phone and other operations.
• Support A2DP Bluetooth music playback: you can easily play Bluetooth device audio through the original car stereo.
• Bluetooth AVRCP control technology: you can use the car audio host (or steering wheel) to control the song selection/fast forward/fast rewind/pause, convenient and safe control.
• High fidelity sound quality: Bluetooth host output to the car stereo through a wired connection, eliminating any interference and sound quality loss, sound quality comparable to CD.
• Adopt bluetooth 5.0 protocol, compatible with 2.0 3.0 4.0 other versions of bluetooth protocol.
• Support common MP3 format audio, and also support WMA, WAV, FLAC, and other high-quality audio format decoding, non-general ordinary bluetooth function.
• USB Function: Supports USB flash drives and flash cards (USB support up to 8GB), support radio panel control.
• Support 3.5 mm AUX Input: Standard 3.5 mm AUX input, you can enjoy music from all AUX possible device, like MP3 player, Mobile Phone, PSP, MP4, etc. Please note 3.5mm AUX NOT support Radio Panel Control.
• This item Work with iPod/iPad/iPhone,Samsung,HTC,Sony,Nokia and any other phones or pads (Please make sure there is bluetooth function in your phone or pad).
• Cable length: approx 20cm

Compatibility:

Toyota
• 4runner 2003-2011
• Avalon 2005-2011
• Avensis 2003-2011
• Auris 2007-2011
• Camry 2005-2011
• Celica 2003-2005
• Corolla 2005-2011
• FJ cruiser 2007-201
• Highlander 2004-2011
• Land cruiser 2003-2011
• MarkX 2005-2011
• MR2 2004-2010
• Matrix 2005-2011
• RAV4 2003-2011
• Sequoia 2005-2011
• Sienna 2004-2010
• Solara 2004-200
• 8Tacoma 2005-2011
• Trundra 2004-2011
• Venza 2009-2011
• Vitz 2006-2010
• Yaris 2006-2011

Lexus
• ES 300/330 2004-2011
• IS 220/250/300/350 2006-2011
• GS 300/400/430/450H 2006-2011
• GX 470 2004-2009
• LS 460 2007-2011
• LX570 2008-2011
• RX300(requires YT-SBY cable) 1998-2002
• RX300/330/350/400H 2004-2009
• SC430 2005-2010

Scion
• xA 2004+
• xB 2004-2013
• tC 2005-2010

Please note:
• Not compatible with Navigation, DVD and Touch Screen radios.
• The Splitter/Y cable is needed if the CD changer port is occupied by others (except for being occupied by CD Changer).

Not work with following radio model:
52867(Vios), Aygo, 58805(2003 RAV4 ), 56018, 58813, T18303, B9010, B9004(2007 RAV4), RAV4 with a factory navigation, TNS Travel 700, P1718, P3905, P6813, P6832, WH8403, W58816, T18303, W13807/W13081/W13086 (Auris), W53904(Panasonic, Avensis 2007), W58824, W58832,36458, AD1812(Delphi on 2010-2011 Tundra/ Sequoia),AD6900(Delphi on 2000-2004 Avalon), other AD-xxx radios

Product parameters:
• Specification size: 70*45*15 (mm)
• Support decoding format: WAV /MP3/APE/WAVE/FLAC(lossless format)
• Support external: USB2.0 /AUX
• Frequency response: 20-20K Hz
• Bluetooth version: 5.0BR/EDR (including compatible with versions below 5.0)
• Distortion: < 0.05%
• Signal to Noise Ratio: > 90dB
• Standby power consumption: > 0.1W
• Operating temperature: -20 - +70°C
• Operating power: DC11-15V (generally taken from the host, no external power supply)
• USB output: DC 5V/300mA

Original car button function (or refer to the car manual)
1, CD-C, CD, DISC, SRC, CD/AUX, etc. for the disc box switching keys
2, DISC+/DISC- etc. for up and down discs (1-6)
3, short press Track +Seek / Track- Seek, etc. for up and down songs (1-99)
4, long press Track +Seek / for single song repeat / sequence play switch
5, long press Track -Seek / Random Play
6, volume, pause, mute and host operation the same
7, Bluetooth priority, disconnect Bluetooth after playing U disk, no U disk switch to AUX.
8. Bluetooth phone MIC default is running in the background, regardless of which option can be used, press a song to connect the phone, press a song to hang up the phone.

Package included:
1 x Module Unit
1 x Aux Cable
1 x Mic Cable
1 x User Manual

************************************************************************************************
