Hydraulic Primer Pump Unit Motor// 12V// CW// DBB// Keyway Shaft Hydraulic Motor for American Godiva, Hale Primer Pumps, Power Wheels Equipment

Applications:
American Godiva, Hale Primer Pumps, Power Wheels Equipment

Part #: 51060
Voltage: 12.00
Rotation: CW
Field Housing Outside Diameter: 4.50 in.
Overall Length: 8.929 in.
Shaft Outside Diameter: 15.8 mm
Shaft Style: Keyway
Terminal 1 Size: 5/16 - 18
Weight: 19
Notes: Double ball bearing. For a motor that includes solenoid, please reference part number 51061.
Cross References:
Prestolite 46-2155 Prestolite 46-2244Prestolite 46-2605 Prestolite 46-555Prestolite 46-557Prestolite MCL-6115Prestolite MCL-6225 Prestolite MCL-6225A Prestolite MCL-6228 Prestolite MCL-6401Prestolite MCL-6508Prestolite MCL-6508T Lester 10718 Lester 160-815 Hale 200-0040-00 Replaces part# Prestolite 46-2155Prestolite 46-2244Prestolite 46-2605Prestolite 46-555Prestolite 46-557Prestolite MCL-6115Prestolite MCL-6225Prestolite MCL-6225A Prestolite MCL-6228 Prestolite MCL-6401Prestolite MCL-6508Prestolite MCL-6508T Lester 10718 Lester 160-815 Hale 200-0040-00
