OWON AG2062F 60MHz 250MS/s Function generator DDS Arbitrary Waveform GeneratorModel No.: AG2062F Product Features- Advanced DDS technology, max 60MHz frequency output - Up to 250MS/s sample rate, and 1μHz frequency resolution - Vertical Resolution : 14 bits, up to 1M arb waveform length - Comprehensive waveform output : 5 basic waveforms, and 45 built-in arbitrary waveforms - Comprehensive modulation functions : AM, FM, PM, FSK, Sweep, PWM and Burst - High-accuracy frequency counter integrated, supported range 100mHz - 200MHz - Supported SCPI - 4 inches high resolution (480 × 320 pixels) TFT LCD display Product descriptionOWON AG2062F is dual-channel arbitrary waveform generators, using advanced DDS technology, AG2062Fup to 60MHz frequency output, high resolution to 1uHz, sample rate 250MS/s. It can output 5 basic waveform, 45 built-in arbitrary waveform. Arb waveform length to 8K. AG2062F supports Comprehensive modulation functions AM, FM, PM, FSK, Sweep, PWM and Burst. Sine 1uHz~60MHz, Square 1uHz~30MHz, Pulse 1uHz ~10MHz, Ramp 1uHz~1MHz, Noise 25MHz(-3dB)(typical), Arb 1uHz~10MHz. Amplitude Max to 20Vpp under high impedance, with resolution 1mV. Optional power amplifier module is supported, max output voltage 22Vpp. Dimension 235 x 110 x 295 mm, 3.00kg. Very good-quality products, worth to have.Package:Power cord (1pc)CD Rom (1pc)Quick Guide (1pc)USB Cable (1pc)Q9 cable (1pc) Dimension: 235x110x295mm Weight: 3.00kg
