Model: VDS6102AWarranty: 12 monthsBandwidthVDS6102A8-bit mode 100 MHz12-bit mode 100 MHz14-bit mode 20 MHzVertical Resolution (A/D): 8 bits/12 bits/14 bitsSampling Rate2-CH working8-bit mode 500 MS/s12-bit mode 250 MS/s14-bit mode 100 MS/s1-CH working8-bit mode 1 GS/s12-bit mode 500 MS/s14-bit mode 100 MS/sRise Time: ≤ 2.3 nsHorizontal Scale: (s/div) 5ns/div - 100s/div, step by 1 - 2 - 5Sampling Mode: sample, peak detect, averageChannel Q'nty 3 (2 main one + 1 auxilary)Record Length: max 10MInput Coupling: DC, AC, groundInput Impedance: 1 MΩ ± 2%, in parallel with 15 pF ± 5 pFMax Input Voltage : 40 V (DC + AC Peak)DC Gain Accuracy: 2% when ≥ 2 mVVertical Sensitivity: 2 mV/div - 5 V/divTrigger Type: edge, video, slope, pulse2Trigger Mode: auto, normal, singleLine/Field Frequency (video): supported standards: NTSC, PAL and SECAM broadcast systemsAutomatic Measurement: Vpp, Vmax, Vmin, Vtop, Vbase, Vamp, Vavg, Vrms, Overshoot, Preshoot, Freq, Period, Rise Time, Fall Time, Delay A→B , Delay A→B , +Width, -Width, +Duty, -DutyFunction Generator PartStandard Waveforms: sine, square, ramp, and pulseFrequency Output: 5 MHzSampling Rate: 25 MSa/sChannel Q'nty: 1Vertical Resolution: 10 bitsAmplitude Range: 10 mVpp – 5 VppDC Offset Range (AC+DC): ± 2.5VOutput Impedance: 50 Ω (typical)General PartCommunication Interface: USB device (type-C), USB host (Wi-Fi extension supported), LANWi-Fi Module: available in optionPower Source: 5 - 15 VDC / 1.2APower Consumption: ≤ 8 WDevice Dimension: w/h/d 190 x 120 x 18 mmWeight: 0.38 kg
