Model No: HW0021-2
Ssystem System Security Supports there-level account, password, user authority management.
OS Embedded Linux OS
Processor GK7102C+GC1034
P2P (Free) No need to preset camera, Offer free P2P(IIII-xxxx-xxxxx), Plug&play, Support QR code scanning to view
Onvif Protocol Support ONVIF2.1 Protocol
Multi-device function Support remote surveillance, record, alarm, wifi setting etc.
PC client Support remote multi-devices monitor, record, alarm etc;Support windows and mac os
Cell Phone View Self R&D APP, Support Iphone,Android smart Phone
TF Card Record Support Max 64G TF card .Support the scheduled record,scheduled snapshot,Support Intelligent record playback via browser
Lens Lens Type Lens Standard : 3.6 mm
IR-CUT Build-in IR CUT, no color cast,auto switch when IR on
Video Image Compression H.264/MJPEG
Sensor 1/4 Cmos 1MP
Video Parameters Brightness, Contrast,Saturation,Exposure,sharpness,VerticalAnd Horizontal can be adjusted
Image Frame Rate 50Hz:25fps/60HZ:30fps (1280×720)
First Stream 720P-(1280x720),(640x352)
Second Stream VGA-(640x352),(320x176)
Audio Compression format G.726/G.711(G.711 Default)
Audio In Built in Mic,also external supported
Audio Out Built in Speaker,also external supported
Night Vision Night Visibility 6 Φ5 IR LEDs, Night visibility up to 15 meters
LUX 0 LUX
Pan/Tilt Preset Support 8 Preset Positions
Rotation Angle Pan:355°, Tilt: 90°
Rotation Speed Pan: Speed Range 5-30°/ S; Tilt: Speed Range 5-50°/ S;
Alarm Motion Detect Support 4 Independent detection areas(Sensitivity can be adjustd 1-100)
Alarm Action Support Email Photo Alert,Snapshot and Record uploaded to FTP or TF Card
Network Ethernet Interface One 10/100Mbps RJ-45
Supported Protocol TCP/IP,HTTP,TCP,ICMP,UDP,ARP, IGMP,SMTP,FTP,DHCP,DNS,DDNS,NTP,UPNP,RTSP etc.
Access agreement Support ONVIF2.1 Protocol
IP Mode Dynamic IP address, static IP address, PPPOE
Online Visitor Support Max 6 visitors at the same time
(First Stream:3 visitors;Second Stream:3 visitors)
Supported OS Support Microsoft Win XP/Win7/Win8/ win10/Mac OS.
Browser Support Internet Explorer8-11 ,FireFox,Google Browser, etc
One key setting Function Support one key setting function connect WIFI
Wireless Standard WIFI, 802.11b/g/n
Others OSD Support the OSD name, date and time info superposition(Open/Off)
Product Type Cartoon Robot/ Indoor use
Color White;
Power DC5V 1A
Working Temperature -10~50 °C
Working Humidity 95% RH
Size Item: 85*70*100mm (LxWxH); Packaging: 182mmx118mmx149mm (LxWxH)
Weight N.W.: 280g G.W.: 600g(Note:Actual Weight Final)
Accessories Adaptor, CD,User manual,Bracket,Screws,Ethernet Cable
Certification CE,FCC,RoHS
Warranty Limited 2-Year Warranty
