Store New Arrivals Add to Favorite View Feedback Contact 5 Inch TFT LCD 1080P / 5MP 4 IN 1 TVI AHD CVI Analog CCTV Tester Security Camera Tester Monitor HDMI Input Audio Test Description Product Details Item specifics Model Number: MATC-IV8 / MATC-IV8W Brand Name: BOAVISION Item Type: CCTV Tester LCD Screen: 5.0 inch TFT-LCD, (RGB) 800x 480 resolution Video Test: NTSC/PAL (Auto adapt) LCD Adjustment: Brightness, Contrast, Saturation adjustable Video IN/OUT: 1Ch BNC Input & 1Ch BNC Output VGA/HDMI input: Max support 1920X1080 video input PTZ Controller: Support RS485 DC12V Power Output: Output DC12V1A power for camera Audio input test: 1Ch audio signal input Battery: Built-in 18650 2600mA battery X 2 Dimension: 194mm x 112mm x 48mm / 540g Product Description BOAVISION 5 Inch TFT LCD 1080P 5MP 4 IN 1 TVI AHD CVI Analog CCTV Tester Security Camera Tester Monitor VGA HDMI Input Audio Test The 4 IN 1 Testerl support TVI CVI AHD Analog CVBS camera testing, VGA video signal input, HDMI1.0 signal input, RS485 data searching, cable testing, LED lamp etc; Product overview: The new HD coaxial tester is developed for the on-site installation and maintenance of HD coaxial camera, like TVI,CVI, AHD,Analog, CVBS. It also provides many useful functions, such as video display, PTZ control, DC12V output power, audio test, image generator, VGA video signal input, HDMI1.0 signal input, RS485 data searching, cable testing, high precision digital multi-meter, LED lamp etc. Key feature * Build in High-resolution 5.0 inches 800 (RGB) x480 wide viewing angle display, * Support PAL/NTSC standard video signal. CVBS testing. * PTZ controller Support Pelco-D / P PTZ control protocol, etc. , through RS485 interface, the user can control the PTZ up, down, left, right rotation, and adjust one machine zoom, focus, aperture size. * Image generator Multi-format video OUT port image generator, sending a variety of standard PAL, NTSC) color graphics section * DC12V 1A output power Power the camera with DC12V (1A) power from the tester. * Audio testing Test the audio input from pickup devices. Connect the tester and pickup device with the audio cable. * Improvement cable test UTP cable, telephone cable etc order and connectivity test, can save testing report * VGA/HDMI input Support 1920X1080VGA/HDMI 1.0 video input, HDMI or VGA is optional via switch. * TVI camera test HD TVI video surveillance testing, support 720p 25, 30, 50,60fps/ 1080p 25,30fps. When TVI signal input, the tester will display HD TVI camera image. (5MP 25,30fps Optional Choose) * CVI camera test HD TVI video surveillance testing, support 720p 25, 30, 50,60fps/ 1080p 25,30fps. When TVI signal input, the tester will display HD TVI camera image. (5MP 25,30fps Optional Choose) * AHD camera test HD video surveillance testing, support AHD 2.0 version, 720p 25,30fps/ 1080p 25,30fps. When AHD signal input, the tester will display the AHD camera image. (5MP 25,30fps Optional Choose) * LED lamp It is useful for the engineer to install and maintain security system at night. LED On/Off pressing button, easy to operate. Specification Model MATC-IV8 / MATC-IV8W LCD screen 5.0 inch TFT-LCD, 800（RGB）x 480 resolution Video test NTSC/PAL (Auto adapt) LCD adjustment Brightness, Contrast, Saturation adjustable Video IN/OUT 1 channel BNC Input & 1 channel BNC Output VGA/HDMI input Max support 1920X1080 video input PTZ Controller Support RS485 PTZ Protocol Compatible with protocols PELCO-D/P, Baud Rate Baud Rate: 600,1200, 2400, 4800, 9600, 14400bps Color bar generator Support both PAL / NTSC format’s standard color bar output (Red, Green, Blue, White, Black, Grey) and testing image output UTP Cable Test Display UTP cable connection status , cable type and the sequence of wires as well as read the number of the test box. DC12V power output Output DC12V1A power for camera Audio input test 1 channel audio signal input Coaxial HD test TVI test 1 channel TVI input(BNC interface), support 720p 25 / 30 / 50 / 60fps, 1080p 25 / 30fps (5MP 25 / 30fps Optional Choose) CVI Test 1 channel TVI input(BNC interface), support 720p 25 / 30 / 50 / 60fps, 1080p 25 / 30fps (5MP 25 / 30fps Optional Choose) AHD Test 1 channel AHD input (BNC interface）, support AHD 2.0 version, 720p 25 / 30fps, 1080p 25 / 30fps (5MP 25 / 30fps Optional Choose) POWER Power Adapter DC 5V（1.5A） Battery Built-in 18650 2600mA battery X 2, After charging 3-4 hour, working time lasts 11 hours General Language English and Chinese optional Working Humidity 30%-90% Dimension 194mm x 112mm x 48mm / 540g Packing List 1* HD 1080P Coaxial Tester (5MP Tester Optional Choose) 1* Adapter DC5V 1.5A（with USB cable) 2* International Standard 18650 2600ma battery 1* BNC cable 1* RS485 connector 1* Power output conversion cable 1* Audio cable 1* Lanyard 1* Tool bag 1* Instruction Manual Packaging Details Unit Type: piece Package Weight: 0.85kg (1.87lb.) Package Size: 30cm x 15cm x 10cm (11.81in x 5.91in x 3.94in) ABOUT US We offer the best prices around on high quality products. Our E-store includes media such as books, movies, music and games while offering electronics, toys, sporting apparel, clothing, tools, general home, garden items and more. SHIPPING We are always working hard to ensure your package arrives as soon as possible. Please understand that some factors like weather, high postal traffic, and the performance of shipping companies are outside of our control. We offer free worldwide shipping. All items are shipped directly from our different suppliers within 1-4 business days. RETURNS We offer a 30-Day Return Policy on items in which you are not completely satisfied with. You have the option of a full-refund or an exchange of the item. Customer is responsible for the the return shippung cost. We do not accept a return of physically damaged items. PAYMENT We accept PayPal. CONTACT US This page content is yet to come Please ad us to your favorite seller and visit again later Thank You CUSTOMER SATISFACTION We try our very best to make sure every customer is completely satisfied. If there's a problem, message us! We're happy to help. WE ACCEPT Copyright © 2018 MasterSeller4Ever. | All Rights Reserved On Aug-27-18 at 17:22:24 PDT, seller added the following information: Further top products See other items FIJON FJ9 1/10 Front Engine Design RC Car Parts Drift Frame Kit Electric carbon USD 366.00 Buy it now ZD Racing 10427S 1:10 Thunder ZMT-10 2.4GHz RTR Brushless Off Road Rc Car USD 169.99 Buy it now DHK Hobby 1/8 4WD Brushless Electric Buggy Optimus XL 8381 RC Car USD 437.99 Buy it now RC Toy Remote Control 6CH Big Dump Truck 6 Functional Loaded Sand Vehicle Toys USD 71.99 Buy it now Full Tang Kitchen Knife Chef Knives Handmade Forged High carbon Clad Steel USD 57.99 Buy it now 16pcs Colors Eternal Tattoo Ink Set Pigment Bottle Permanent Makeup Art 1OZ 30ml USD 46.99 Buy it now Free Shipping Alloy Steel Sharp Kitchen Slicing Meat Chef Knife Household Cookin USD 25.95 Buy it now Tesla Rotating Egg Columbus Egg Single Phase AC Motor Rotating Magnetic Field USD 595.00 Buy it now Tesla Rotating Egg Columbus Egg Single Phase AC Motor Rotating Magnetic Field USD 597.00 Buy it now BAYANGTOYS X22 Brushless Dual GPS WIFI FPV with 3-Axis Gimbal 1080P Camera RC Dr USD 265.00 Buy it now DJI Smart Controller Transmitter with 5.5-inch 1080P Screen OcuSync 2.0 Go Share USD 804.98 Buy it now ALIGN T-REX 500X Helicopter Dominator Super Combo USD 767.43 Buy it now Powered by Supreme supremeproductonlinesoftware.staticWidgets.templateBased
