Motor for Warn Winch 20 Spline Shaft M1900 MRV Style
Application:
ARCO MARINE, WARN INDUSTRIES, WARN WINCH




Motor for Warn Winch 20 Spline Shaft M1900 MRV Style
Brand:
Warn Aftermarket

Warranty: Yes Manufacturer Part Number:
8403, 31560, 38894, MRVB7, MRVB4, 51004
*12V
(BI-DIRECTIONAL
3 POST
DBB
WINCH MOTOR WITH 20 SPLINE SHAFT & OLP
Motor for Warn Winch with 20 Spline Shaft

•Part #: 51004
Rotation: Bi-Directional
Overall Length: 9.154 in.
Shaft Outside Diameter: 0.654 in.
Shaft Style: 20 Spline
Terminal 1 Size: M8 - 1.25
Terminal 2 Size: M8 - 1.25
Housing Finish: Black field case
Weight: 17.6 lbs.

Notes: Also available in 4.8 HP, see motor# 51009.
•

•Aftermarket
•9 Month Warranty
Application:

•M1900
•Arco Marine
•Superwinch
•Warn Industries
•Warn Winch


Replaces MPN

•Prestolite MRVB4, MRVB7
•Warn 8403, 31560, 38894
•Cross References:
Iskra: 11-216-273,
•Iskra: AMJ4635
Lester: 10746, 10747, 160-799, 160-800
Prestolite: MRV-B-4, MRV-B-5, MRV-B-7
Superwinch: 2401, 2404, 31681, M-2401, M-2404, MRV-B-4, MRV-B-5, X9
Warn: M25314,
•Warn M25981
•Warn M25982

51004




Replaces part #




Iskra11-216-273, AMJ4635
Lester: 10746, 10747, 160-799, 160-800
Prestolite: MRV-B-4, MRV-B-5, MRV-B-7
Superwinch: 2401, 2404, 31681, M-2401, M-2404, MRV-B-4, MRV-B-5, X9
Warn: M25314, M25981, M25982




This motor will replace the following part #'s

Iskra: 11-216-273, AMJ4635
Lester: 10746, 10747, 160-799, 160-800
Prestolite: MRV-B-4, MRV-B-5, MRV-B-7
Superwinch: 2401, 2404, 31681, M-2401, M-2404, MRV-B-4, MRV-B-5, X9
Warn: M25314,
Warn M25981
Warn M25982
MODELS, MX12085, M12000, MX10000, M10000, M8274,

( SUPERWINCH HUSKY SERIES )
REPLACES NUMBERS, W5623, 81560, 39322, 15747, 17102, MRVB4, 18184, MRVB5, F000MM0618, 31681, 2401, 2404, MCV-B-4, MRV-B-4, MRV-B-5
