24V Motor for Ramsey Pierce and Vime Winches 3 Posts
Brand:
Ramsey Aftermarket

Replaces Ramsey 458002: Replaces Ramsey 458005 Manufacturer Part Number:
MMD4001, MMD4401, W8956, 10730

Replaces WMS: W8956, W-8956: Replaces Western Motor Service # W8956 Warranty: Yes
Replaces Prestolite MMD4001: MPN: Prestolite MMD4401

Part #: 51002
Voltage: 24.00




Aftermarket Motor

PICK UP IN KOKOMO, INDIANA IS AVAILABLE


Rotation: Bi-Directional, Bi-Rotational, Reversible
Field Housing Outside Diameter: 4.524 in.
Overall Length: 9.311 in
Shaft Outside Diameter: 0.748 in.
Shaft Style: Includes keyway
Terminal 1 Size: 5/16 - 24
Terminal 2 Size: 5/16 - 24
Terminal 3 Size: 5/16 - 24
Housing Finish: Cast aluminum drive end with a black field case.

9 Month Warranty
Weight: 19.44 lbs
We are an All American small business and need your Patronage. Thank you.

Cross References:

•M3300 - 24V


•PS-534 - 24V


•WMS W8956



Replaces OEM part #'s:

•Prestolite: 46-2289


•Prestolite 46-3523


•Prestolite MMD4001


•Prestolite MMD4401


•Prestolite MMD6102
Ramsey: 458002


•Ramsey 458005
Lester: 10730


•Lester 160-918


•Western W-8956


•WMS W8956


•WMS-8956


51002

Replaces part #
51002

Replaces part #

•Prestolite: 46-2289


•Prestolite 46-3523


•Prestolite MMD4001


•Prestolite MMD4401


•Prestolite MMD6102
Ramsey 458002


•Ramsey 458005
Lester 10730


•Lester 160-918


•WMS W8956


•Western WMS8956


•Western WMS-8956


This motor will replace these OEM #'s on Ramsey, Pierce and Vime Winches

•Prestolite: 46-2289


•Prestolite 46-3523


•Prestolite MMD4001


•Prestolite MMD4401


•Prestolite MMD6102
Ramsey 458002


•Ramsey 458005
Lester 10730


•Lester 160-918
