Winch Motor// 24V// Bi-Directional// Keyway Shaft
Applications:
Ramsey Winches
Vimes Winches
Pierce Winche
sPart #: 51002
Voltage: 24.00 Aftermarket Motor Rotation: Bi-Directional Field Housing Outside Diameter: 4.524 in. Overall Length: 9.311 in Shaft Outside Diameter: 0.748 in. Shaft Style: Includes keyway
Terminal 1 Size: 5/16 - 24
Terminal 2 Size: 5/16 - 24
Terminal 3 Size: 5/16 - 24
Housing Finish: Cast aluminum drive end with a black field case.
Weight: 19.44 lbs
Cross Reference
:M3300 - 24VPS-534 - 24V
Prestolite: 46-2289, 46-3523, MMD-4001, MMD-4401, MMD-6102
Ramsey: 458002, 458005
Lester: 10730, 160-918
Western W-8956
Replaces part #Prestolite: 46-2289, 46-3523, MMD-4001, MMD-4401, MMD-6102
