Aftermarket

12V//4 Post//Insulated Ground Solenoid w/Flat Bracket
Part #:57315
Notes:Phenolic case and a flat mounting base with copper contacts and terminals. (2) 5/16 - 18 Threaded Motor & Battery Studs, (1) 10-32 switch terminal and (1) 10-32 ground terminal
.Cross References:Lester©: 6600-1047 Prestolite©: 15-400, 15-487, SAZ-4201AHY, SAZ-4201EY

Replaces:Mercury Marine 89-68258, 89-68258A4
Prestolite15-400, SAZ4201AHY, SAZ5201AHY
Volvo-Penta852565SMR6005

ARROWHEADSMR6005K ATLANTICSMR6005K2 ATLANTIC6699-205 PIC10-FO1068 ACCUMAX10-PT1487 ACCUMAX7-1068 ACCURATESW275 ARCO MARINESW565 ARCO MARINE89-68258 MERCURY MARINE89-68258A4 MERCURY MARINE3365M MES MOTORCYCLE & MARINE4-1208 MP PARTSSAZ5201AHY PRESTOLITE15-400 PRESTOLITESAZ4201AHY PRESTOLITE15-375 PRESTOLITE18-5815 SIERRA MARINE852565-1 VOLVO PENTA852565 VOLVO PENTA67-710 WAIItem Specifics:OEM(s): Prestolite, Ametek, Mercury MarineVoltage: 12 VoltsTerminals: 4 - (2) 5/16-18 Terminals / (2) 10-32 TerminalsDuty Cycle: Intermittent DutyNotes:5/16-18 Threaded Motor & Battery Studs10-32 Threaded Excitation & Ground TerminalsFlat Mounting Base with 7mm Mounting Holes-60mm & 180 Degrees ApartSAE-J1171 Marine CertifiedAmp Rating:100 Amp Intermittent Current RatingInterchange Numbers:Mercury Marine89-68258, 89-68258A4Prestolite15-400, SAZ4201AHY, SAZ5201AHYVolvo Penta852565Starter Solenoid For Mercury/Mercruiser Outboards20 (200,20) 4709593 thru 6443972 40 (2 Cylinder) 5556230 thru 5823917 45 (4 Cylinder) 5531630 thru 6146848 50 (50,500) 4 Cylinder 5531630 thru 6146848 65 (650) 3 Cylinder 3547987 thru 4571651 70 (3 Cylinder) 4571652 thru 6104369 80 (800) 4 Cylinder 4831999 thru 5582561 80 (4 Cylinder) 5582562 thru 6030903 85 (850) 4 Cylinder 3865695 thru 4831998 90 (90, 900) 6 Cylinder 4845301 thru 6026608 115 (115, 1150) 6 Cylinder 4112635 thru 5600966 115 (6 Cylinder) 5600967 thru 6051525 140 (140, 1400) 6 Cylinder 485678 and up 150 (1500) 6 Cylinder 4121435 thru 4865677 150 (1500XS) 4868648 thru 5327662 105 Jet V-6 Flush Mounted Solenoid Not Rubber Mounted 0D082000 thru 0G303045 V-135 with 5/16-18 Starter Solenoid Terminals 0A904646 thru 0C100860 V-135 0C100861 thru 0D081999 V-135 Flush Mounted Solenoid Not Rubber Mounted 0D082000 thru 0G303045 V-150 Mercury 5432022 thru 6042945 V-150 Mariner 5432022 thru 6038680 V-150 with 5/16-18 Starter Solenoid Terminals 0A904646 thru 0C100860 V-150 0C100861 thru 0D081999 V-150 Flush Mounted Solenoid Not Rubber Mounted 0D082000 thru 0G303045 V-150 EFI Flush Mounted Solenoid Not Rubber Mounted 0D082000 thru 0G303045 V-150 XR4 0B242885 thru 0D081999 V-150 XR6 Flush Mounted Solenoid Not Rubber Mounted 0D082000 thru 0G303045 V-175 (V-175, V-1750) 4301235 thru 6618750 V-175 with 5/16-18 Starter Solenoid Terminals 6618751 thru 0C100860 V-175 0C100861 thru 0D081999 V-175 Flush Mounted Solenoid Not Rubber Mounted 0D082000 thru 0G303045 V-175 EFI 0D000750 thru 0D081999 V-175 EFI Flush Mounted Solenoid Not Rubber Mounted 0D082000 thru 0G201874 V-200 (V-200, V-2000) 4839034 thru 603191 V-200 with 5/16-18 Starter Solenoid Terminals 6625221 thru 0C100860 V-200 0C100861 thru 0C291519 V-200 (2.5L) 0C291520 thru 0D081999 V-200 EFI Flush Mounted Solenoid Not Rubber Mounted 0D082000 thru 0G303045 V-200 EFI (2.4L) 0C100861 thru 0C291519 V-200 EFI (2.5L) 0C291520 thru 0D081999 V-200 Flush Mounted Solenoid Not Rubber Mounted 0D08200 thru 0G303045 V-220 Laser 0B117316 and up V-225 (2.4L) 56280028 and up V-250/275 (3.4L) 0C101891 and up V-300 (3.4L) 5611648 and upTrim Solenoid Mercury/Mercruiser Outboards45 (4 Cylinder) Without Trim Circuit Breaker & Fuse 5531630 thru 0B110788 50 (4 Cylinder) Without Trim Circuit Breaker & Fuse 5531630 and up 70 (3 Cylinder) 5579017 thru 6428680 80 (4 Cylinder) Without Trim Circuit Breaker & Fuse 5582562 thru 6432900 90 (90, 900) 6 Cylinder 4845301 thru 5594656 90 (6 Cylinder) Without Trim Circuit Breaker & Fuse 5594657 thru 6436122 115 (115,1150) 6 Cylinder 4112635 thru 5600966 115 (6 Cylinder) Without Trim Circuit Breaker & Fuse 5600967 thru 6051525 140 (140, 1400) 6 Cylinder 4865678 and up 150 (1500XS) 4868648 thru 5327662 V-175 (V-175, V-1750) 4301235 thru 6618750 V-200 (V-200, V-2000) 4839034 thru 6073191 V-225 (2.4L) 5628028 and upStarter Solenoid Mercruiser Outboards120 153 L4 1976 - 1982 4469866 thru 6229717 140 181 L4 1976 - 1981 4460665 thru 6229717 165 (6 Cylinder) 250 L6 1976 - 1981 4471566 thru 5813433 198 MIE 305 V-8 1977 4776402 thru 4931099 228 MIE 305 V-8 1977 - 1980 4765100 thru 5907057 255 (GM) 350 V-8 1975 - 1976 4175500 thru 4767999 255 MIE (GM) 350 V-8 1975 - 1980 4175500 thru 5907057 280 TRS 350 V-8 1975 - 1976 4176250 thru 4770199 330 454 V-8 1977 - 1981 4623115 thru 6083144 330 MIE 454 V-8 1977 - 1980 4623115 thru 5889913 370 TRS 454 V-8 1978 - 1985 4179554 thru 6721527 400 TRS 454 V-8 1980 - 1986 4179554 thru 0B457644 440 TRS 454 V-8 1983 - 1986 4179554 thru 0B485220 460 TRS 482 V-8 1983 - 1986 4179554 thru 6181046
