New Lanch Baofeng UV-89 Walkie Talkie Dual display Dual band VHF & UHF Two Way Radio UV89


Features:

- Dual Band, Dual Display, Dual Frequency,Dual Standby
- A/B band independent operation
- 128 groups channels storage
- Shortcut menu operation mode
- VFO & Memory channels scan
- Emergency Alarm
- Tri-color background light selectable
- 0~9 grades VOX selectable
- PTT & ANI ID
- FM radio and 25 stations storage
- 1750Hz Brust
- Tone Time-out Timer
- Channel Monitor
- Battery Saver
- Keypad Lock
- Channel Step: 2.5/5/6.25/10/12.5/25KHz
- Low Battery Alert
- ROGER SET
- Emergency Alert
- 25KHz/12.5KHz Switchable
- FM Radio (65.0MHz-108.0MHz)
- Large LCD Display
- LED Flashlight
- Hight /Low RF Power Switchable
- Voice companding
- 50 CTCSS/ 104DCS coder & tone searching
- dual standby
- PC programmable
- Wide/Narrow Band(25kHz/12.5kHz)
- Transmitter time-out timer(TOT)
- High/Low TX power selectable
- Busy channel lock-out(BCLO)



Specifications:

Frequency Range
65-108MHz(FM Receive only)


136-174MHZ and 400-520MHZ (TX/RX)

Channel No.
128

Frequency Stability
±2.5ppm

Antenna
High gain DualBand antenna

Antenna Impedance
50?

Operating Voltage
DC 7.4V

Mode of operation
Simple or semi-duplex

Antenna :
SMA -Female

Earpiece / mic type :
Kenwood Plug type

Dimension(W x H x D)
132 x 60 x 35 mm (not included antenna)

Weight
238g(including battery, antenna)

Power adapter
Input: AC100-240V, 50-60Hz;

Output: DC10V/500mA;

Plug Type: US

Output power
5W / 1W (Max 5W)

Modulation Mode
16k F3E / 11k F3E

Maximum deviation
5kHz(Wide) / 2.5kHz(Narrow)

Spurious Radiation
7W

Adjacent Ch. power
-65dB(Wide) / -60dB(Narrow)

Pre-emphasis characteristics
6dB

Current
1.6A(5W)

CTCSS/DCS deviation
0.5±0.1kHz(Wide) / 0.3±0.1kHz(Narrow)

Intermediation sensitivity
8-12mv

Intermediation distortion
10%
