Features
Powerful high-speed video protocol processor. Optimized MJPEG video compression for transmission. Multi-level users management and passwords definition. Embeded Web Server for users to visit by IE. Support wireless network (Wi-Fi/802.11/b/g)mobile, two way audio. Supporting Dynamic IP (DDNS)and UPnP LAN. With automatic opened infrared rays, night vision distance can reach up to 10 metres.Giving alarm in cause of motion detection. Support multiple network protocols: HTTP/TCP/IP/UDP/STMP/DDNS/SNTP/DHCP/FTP.Support remote system update,Multi-Protocol support and Transportation. Sending the image to your mailbox automatically when the IP CAM is triggered. Get the certification of CE, FCC & RoHS.
Specification:
Items IP Camera Image Sensor Image Sensor 1/5 Color CMOS Sensor Display Resolution 640 x 480 Pixels(300k Pixels) Lens f: 3.6mm, F:2.4 (IR Lens) Mini. Illumination 0.5Lux Lens Lens Type Glass Lens Viewing Angle 67Degree Video Image Compression MJPEG Image Frame Rate 15fps(VGA),30fps(QVGA) Resolution 640 x 480(VGA), 320 x 240(QVGA) Flip Mirror Images Vertical / Horizontal Light Frequency 50Hz, 60Hz or Outdoor Audio Function Two-way Talk Video Parameters Brightness, Contrast Communication Ethernet One 10/100Mbps RJ-45 Supported Protocol Supported Protocol HTTP,FTP,TCP/IP,UDP, SMTP, DHCP, PPPoE, DDNS,UPnP, GPRS Wireless Standard IEEE 802.11b/g Data Rate 802.11b: 11Mbps(Max.) 802.11g: 54Mbps(Max.) Wireless Security 64/128-bitWEP Encryption Physical Pan/Tilt Angle Horizontal:270掳 & Vertical: 90掳 Infrared Light 10 IR LEDs, Night visibility up to 10 meters rm Input 1 Channel on/off input Alarm Output 1 Channel relay output Color Black Item Size 10 * 12.3cm Item weight 246g Package size 21.6 * 16.7 * 12.4cm Package weight 611g Q'ty 10pcs/CTN CBM 0.068CBM/CTN Power Power Supply DC 5V/2.0A Power Consumption 5 Watts (Max.) Environment Operate Temper 0掳 ~ 55掳C (14掳F ~ 122掳F) Operating Humidity 20% ~ 85% non-condensing Storage Temper -10掳C ~ 60掳 (14掳F ~ 140掳F) Storage Humidity 0% ~ 90% non-condensing PC Requirements CPU 2.0GHZ or above (suggested 3.0GHz) Memory Size 256MB or above (suggested 1.0GHz) Display Card 64M or above Supported OS Microsoft Windows 2000/XP/Vista/window7 Browser IE 5.0,IE 6.0, IE7.0, IE8.0, firefox2.0, firefox3.0 or other standard browsers Certification CE, FCC, ROHS Warranty Limited 1-year warranty
Package including:
1 * IP Camera1 * Wi-Fi Antenna1 * CD1 * DC Power Supply (5V 2A)1 * Mounting Bracket1 * Network Cable1 * Mounting Accessories
