Model:QL-VWG172
Qualir Recommendation

* All-in-one for
* VW: New BORA / PASSAT CC (From 2008) / PASSAT B6 (From 2006) / JETTA A5 (From 2005) / GOLF PLUS (From 2003) / GOLF 5 (From 2003) / Golf GTI / Golf R32 / Scirocco (From 2008) / Tiguan (2007 to 2009) / Touran / Caddy / EOS / Rabbit (From 2006)
* SKODA: Octavia Limousine (From 2004) / Octavia Combi (From 2004) / Fabia Limousine (From 2007) / Fabia Combi (From 2007) / Roomster (From 2006) / Praktick (From 2007)
* SEAT: Toledo III (From 2004) / Leon II (From 2005) / Altea (From 2004)
* 7" HD Digital touchscreen with 800*480 resolution
* Dolby digital, DTS, Dolby Pro II surrounds
* High Quality assured!
* New OEM Factory-style design. Original factory panel design,original harness and plug compatibility
* Two-Way CAN-BUS communication technology, compatible with most latest VW Vehicles released in 2009 2010



Key Features

* Built-in GPS navigation receiver
* Two-din 7inch touch screen digital TFT LCD (GUI)
* Compatible:DVD/VCD/CD/MP3/MP4/DIVX/8cm discs,SD/MMC slot,USB port
* Built-in AM/FM receiver and amplifier(RDS)
* Electronic anti-shock
* Multi-channel auto-EQ setting
* Picture adjustment (brightness, contrast, color)
* Dolby digital, DTS, Dolby Pro II surrounds
* Optional built-in DVB-T Receiver(MOQ: 10pcs)
* Bluetooth A2DP
* iPod ready
* Original Steering wheel control
* Real time display, Reverse camera input
* Volume/treble/bass/balance/fader controls
* GPS dual zone Navigation System


Product Parameter
Navigation
Operating system Win CE5.0
Chip module SAMSUNG 2440
Max. main frequency 400 MHZ
Memory Storage RAM:33.66/64MB FLASH:35.79/128MB
Precision 10m,2D RMS 5m,2D RMS, WAAS enable
Supported Maps PolNav,iGO,Route66,Gate 5,Papago……
GPS Resolution Output 800*480
Voice Guidance Cruise YES
Media
Audio Media MP3/PCM/WMA
Video Media mp4/mpeg/mpg/asf/wmv/mov/avi/3gp/m4v/mgv/vw/divx/mkv/wvx/mpv
Display
Touch screen 7"/6.2" 16:9 Digital Touch screen, Definition 800*480
Color system PAL/NTSC/SECAM
Language
Main Menu language EN
GPS language EN,Deutsch,Fransais,Espanol,Nederlands,Magyar,Italiano,Cesky,Dansk,Norsk,Svenska,Portuguese,
Finland,Romanian,Polish,Pyccknn.16
DVD language EN
TV
Analog/Digital TV NO (optional built-in DVB-T)
Digital TV Format NO
TV Antenna 1 digital TV antenna if you choose DVB-T
Radio
FM Frequency 87.5-108MHz 0.05MHz
AM Frequency 522-1620KHz 9KHz
RDS YES
Auto search and save NO
Manual search and save YES
Bluetooth
Version Bluetooth 2.0, support A2DP
Bluetooth Handsfree YES
A2DP YES
Built-in microphone YES
Phone Book NO
other functions Received Call, Dialed Call
iPod Control
Support Generation All generations made before 2009
Support Music YES
support video NO
controlling on screen YES
Read play list YES
Charge up the ipod NO
Video/Audio in/out
Video in/out Video-input-1,video-output-1/2,camera
Audio in/out Audio-output-L/R Audio-input-L/R
Aux YES
Subwoofer port YES
CDC port NO
spdif-out NO
SD/USB
Map SD 1 SD slot for Map, Max.16G
Music SD Some models has 1 music SD slot, some models has no individual one
portable hard drive NO
USB 1 USB port in the front, MAX.16G
Operating Environment
Voltage requirement 12V
Current requirement 1.5A
Operating temperature range -20°C-70°C
Accessories
GPS Antenna 1 piece included
Remote control 1 piece included
Wire/Cable 1 power harness
User Manual 1 piece (in English)
USB Cable 1 piece
iPod Cable 1 piece
Touch Pen 1 piece included
Screws for Installation 1 SET
Packing Box
